Communications
Monitor the infrastructure health.
Engineering Connectivity
93%
Healthy
Connected Systems
18 / 19
1 Warning
OPC Tag Quality
99.4%
Excellent
Communication Latency
24 ms
Normal
Collector Status
Running
Healthy
Data Collection Success
99.7%
Last 30 Days
Engineering Connectivity Map
DeltaV System
OPC Servers
Mimic Simulation
Aspen HYSYS Dynamics
Historian Server
Azure Cloud
Data Collection Success (Last 7 Days)
Connected Systems Status
| System | Status | Last Seen | Health % |
|---|---|---|---|
| DeltaV System | Online | 13 sec ago | 100 |
| Mimic Simulation | Online | 9 sec ago | 99 |
| Aspen HYSYS Dynamics | Online | 9 sec ago | 98 |
| Historian Server | Warning | 1 min ago | 84 |
| ProSync Collector | Running | 1 min ago | 100 |
| Azure Cloud Upload | Online | 28 sec ago | 100 |
| Engineering Workstation | Online | 11 sec ago | 97 |
| Backup Storage | Online | 22 sec ago | 98 |
Communication Latency Trend (ms)
Collector Health
32%
CPU Usage
48%
Memory Usage
61%
Disk Usage
2
Pending Queue
0
Errors (24h)
Infrastructure Heat Map
| Area A | Area B | Area C | Area D | Area E | Utilities | |
|---|---|---|---|---|---|---|
| CTRL-101 | 10 | 20 | 15 | 30 | 45 | 20 |
| CTRL-102 | 55 | 60 | 40 | 20 | 15 | 25 |
| CTRL-201 | 70 | 45 | 60 | 80 | 35 | 30 |
| CTRL-301 | 20 | 15 | 25 | 40 | 55 | 60 |
| CTRL-401 | 30 | 40 | 20 | 15 | 25 | 45 |
System Availability (Last 30 Days)
99.8%
DeltaV
99.5%
Mimic
98.7%
OPC
99.2%
Historian
99.9%
ProSync
Top Communication Issues (Last 7 Days)
| Issue | Occurrences | Impact |
|---|---|---|
| OPC Quality Degradation | 4 | Medium |
| Network Latency Spikes | 2 | Low |
| Historian Disconnects | 1 | Medium |
| Upload Delays | 1 | Low |
| Certificate Expiring Soon | 1 | Info |
